Utilizes premium energy-efficient vinyl for exceptional thermal performance.
-
Panels capable of heights up to 9' (2743 mm).
-
Bottom Support.
S
William G
" Ez-Fold-A-Door has always been my go to vendor for a high quality bi-folding door for my installs, I own a patio door company that specializes in installing bi-folding and Panoramic doors called "Patio Door Pro" here in TX. I've worked on countless projects using their door systems and I am always impressed with the quality and service of their products from the little line details of the frame extrusions, to the beefy wheel carriers, high quality trouble free hardware and even the blueish color of the low-E glass sets them at a higher standard than the chinese cookie cutter door systems. They even had their rep "Tom" help on some of the bigger projects ive worked on just to ensure the quality of the project. I can't say enough good things and will continue to use them as my go to quality bi-folding door! "
Performance
Description
Material
UPVC
Panel
Min. Panel Width: 14” (355.6 mm)
Max. Panel Width: 44” (1117.6 mm)
Number of Panels: Unlimited
Max Unit Height
without structural horizontal mullion
[Max. Unit Height with structural horizontal mullion]
9' (2743 mm)
[11'6" (3500 mm)]
Intersection of two folding doors
5 25/32" (147 mm)
Glass Thickness Options
0.6299” (16 mm) / 0.8661” (22 mm)
0.9448” (24 mm) / 1.1024” (28 mm)
1.2598” (32 mm) / 1.2992” (33 mm)
Folding Options
Unlimited (Go to the Fold Options & Special Features Page)
Track Options
Standard UPVC Track (Go to Tracks for details)
Finish Options
UPVC (White)
Center of glass U-Value ≤0.21
Unit U-Value ≤0.21
Wind Design Pressure
Wind Design Pressure
Non-Impact: Testing in Progress
Impact: Testing in Progress
FL-HVHZ (TAS 201/202/203)
Water Penetration Resistance
≥ No leakage after 4 cycles of
5 minutes at 504 pa (10.5 psf)
Air Infiltration 0.145 (cfm/ft2)
Air Exfiltration 0.129 (cfm/ft2)
Rounded Reported Value 0.1
Sound Transmission
STC up to 42
