FoldA Aluminum 54

Basic Aluminum System

Standard aluminum system, featuring excellent energy efficiency, sound transmission, and infiltration capabilities.

ç
  • Offers energy efficiency required for most glass folding systems.

  • Panels capable of heights up to 11’6” (3500 mm) and up to 14’9” (4500 mm) with horizontal mullion.

  • Bottom Support, Top Hung, or Bottom Support/Top Hung with our HD option.

J

John Williams

star rating.png

" So glad I chose this company! I searched for quite some time for an easy access door for my husband’s power chair this is wide enough to allow his sip and puff chair to pass with comfort. This use to be a single 33 inch glass door with a matching 33 inch plate glass window leading to the back yard. It was not safe for his hands, and the doorway was banged often, tearing the edges of the wood and insulation trim. This door opens easy, closes easy, comes in many flexible designs, and was relatively easy to install. We had to allow space/height for the uneven stone floor in the dining room. Otherwise, it recesses into the floor for easy wheelchair access. While designing, we had lots of questions, followed by an extensive customer service conversation, helping us choose EXACTLY what we needed for our situation. Production time was several weeks, but felt like forever until it arrived. We are so glad we chose this company and are 100% pleased with the results of our aluminum, three panel folding door now leading from our dining room into the new wheelchair accessible bedroom/roll in shower. The other choice was trying to find an acceptable space to add an elevator to get up to the master, and then modifying the bathroom completely to accommodate. Thank you EZ-FOLD-A-DOOR!"

System Details

Sample System 3D

Explore the full 4-panel FoldA Aluminum 54 system and its cross-sectional profile in detail.

ez fold a door_ FoldA Aluminum 54_7.avif

The images shown here represent a 4-panel system example only. We offer fully custom solutions, allowing you to choose sizes, fold options, and finishes to perfectly match your needs.

Performance

Description

Material

Aluminum

Panel

Min. Panel Width: 12” (304.8 mm)

Max. Panel Width: 50” (1270 mm)

Number of Panels: Unlimited

Max Unit Height

without structural horizontal mullion

[Max. Unit Height with structural horizontal mullion]

11'6" (3500 mm)

[14'9" (4500 mm)]

Intersection of two folding doors

4 51/54" (122 mm)

Glass Thickness Options

0.1969” (5 mm) / 0.3150” (8 mm)

0.3937” (10 mm) / 0.4724” (12 mm)

0.6299” (16 mm) / 0.8661” (22 mm)

0.9448” (24 mm)

Folding Options

Unlimited (Go to the Fold Options & Special Features Page)

Track Options

Standard Combo Track / Automotive Track /

Freeway Track / HD Track

(Go to Tracks for details)

Finish Options

Froponᵀᴹ PVdf Resin Coatings

(Go to Finishes for details)

Performance

ez fold a door_ FoldA Aluminum 54_11.avif
Center of glass U-Value  ≤0.21
Unit U-Value  ≤0.47

(NFRC Tested and Labeled)

abstract-white-background_476363-6452.avif
Wind Design Pressure
Non Impact : ≥ +70 / -105 psf
Impact : ≥ +70 / -70psf

FL-HVHZ / Tested to TAS201/202/203

ez fold a door_ FoldA Aluminum 54_8.avif
Water Penetration Resistance
≥ No leakage after 4 cycles of
5 minutes at 504 pa (10.5 psf)

Air Infiltration 0.061 (cfm/ft2)
Air Exfiltration 0.073 (cfm/ft2)
Rounded Reported Value 0.1

Exceeds the requirement x3

Sound Transmission
STC up to 42

ez fold a door_ FoldA Aluminum 54_9.avif
Durability
500,000 cycles

Test Passed

ez fold a door_ FoldA Aluminum 54_5.avif
