FoldA Elevate
System for Taller Installations
FoldA Elevate features slim aluminum profiles that offer tall installations an energy-efficient, sleek aesthetic. This design not only enhances the visual appeal of your environment but also ensures durability and superior thermal performance. Heights can be up to 23' with the addition of a horizontal mullion.
-
Offers standard or Thermally Broken AZON™ architectural aluminum, engineered to meet higher wind load requirements for taller buildings.
-
Panels capable of heights up to 11'6" (3500 mm) and up to 23' 7" (7200 mm) with a horizontal mullion and without glass division.
-
Bottom Support, Top Hung, or Bottom Support/Top Hung with HD option.
P
Paper Plane Coffee
" We ordered an EZ Fold A Door accordion door for our cafe during the pandemic, and honestly, it’s been such a great investment. The door itself has held up really well, even with the constant wear and tear of a busy space like ours. It’s easy to use and fits the vibe of our cafe perfectly. What’s been even better is their customer service. From the start, they were super helpful and made the whole process really easy for us. Even now, a few years later, they’ve been quick to answer any questions or help with anything we needed. Couldn’t recommend them more if you’re looking for a good quality door and a company that actually cares about its customers. We’ve been really happy with ours! "
Performance
Description
Material
Aluminum
Panel
Min. Panel Width: 12” (304.8 mm)
Max. Panel Width: 50” (1270 mm)
Number of Panels: Unlimited
Max Unit Height without structural horizontal mullion
[Max. Unit Height with structural horizontal mullion]
11'6" (3500 mm)
[23'7" (7200 mm)]
Intersection of two folding doors
5 53/64" (148 mm)
Glass Thickness Options
0.1969” (5 mm) / 0.3150” (8 mm)
0.3937 ” (10 mm) / 0.4724” (12 mm)
0.6299” (16 mm) / 0.8661” (22 mm)
0.9448" (24 mm)
Folding Options
Unlimited (Go to the Fold Options & Special Features Page)
Track Options
Standard Combo Track / Automotive Track /
HD Track (Go to Tracks for details)
Finish Options
Froponᵀᴹ PVdf Resin Coatings
(Go to Finishes for details)
Center of glass U-Value ≤0.21
Unit U-Value ≤0.47
(NFRC Tested and Labeled)
Wind Design Pressure
Non Impact : ≥ +70 / -105 psf
Impact : ≥ +70 / -70psf
FL-HVHZ / Tested to TAS201/202/203
Water Penetration Resistance
≥ No leakage after 4 cycles of
5 minutes at 504 pa (10.5 psf)
Air Infiltration 0.061 (cfm/ft2)
Air Exfiltration 0.073 (cfm/ft2)
Rounded Reported Value 0.1
Exceeds the requirement x3
Sound Transmission
STC up to 42
Durability
500,000 cycles
Test Passed
