Enhanced with Thermally Broken AZON™, providing superior energy efficiency.
-
Panels capable of heights up to 11'6" (3500 mm) and up to 14'9" (4500 mm) with a horizontal mullion.
-
Bottom Support, Top Hung, or Bottom Support/Top Hung with our HD option.
T
Trish C
" Truly truly a 5 star company, quality of material, precision of parts and most importantly staff. From initial planning to design, shipping and installation, Jin and Tom helped us with every small details to make sure the final product is PERFECT. You really get to know what this company and their people are about, they really won me over. Exceptionally satisfied and grateful for how well they treated me. Every friend came by had great compliments about the doors. Couldn’t be happier! "
System Details
Sample System 3D
Explore the full 4-panel FoldA Aluminum 57 system and its cross-sectional profile in detail.
AZON™ Technology
1 AZON™ (Top)
AZON options on our Standard Top Track
0 AZON™ (Top)
AZON options on our Standard Top Track
_standard%20combo%20bottom%20track_1%20AZON.jpg)
1 AZON™ (Bottom)
AZON options on our Standard Combo Bottom Track
_standard%20combo%20bottom%20track_2%20AZONs.jpg)
2 AZON™ (Bottom)
AZON options on our Standard Combo Bottom Track
_standard%20combo%20bottom%20track_0%20AZON.avif)
0 AZON™ (Bottom)
AZON options on our Standard Combo Bottom Track
AZON™ Technology
1 AZON™ (Top)
AZON options on our Standard Top Track
1 of 2
0 AZON™ (Top)
AZON options on our Standard Top Track
2 of 2
1 AZON™ (Bottom)
AZON options on our Standard Combo Bottom Track
1 of 3
2 AZON™ (Bottom)
AZON options on our Standard Combo Bottom Track
2 of 3
0 AZON™ (Bottom)
AZON options on our Standard Combo Bottom Track
3 of 3
What is AZON?
AZON is a high-performance thermal barrier engineered for commercial-grade aluminum systems. It forms a true non-metal-to-metal break, drastically reducing heat transfer and condensation.
→ Commonly used in curtain walls and storefronts, now integrated into our folding doors.
Powered by AZONᵀᴹ
The Strongest Thermal Barrier for Aluminum
What is AZON?
AZON is a high-performance thermal barrier engineered for commercial-grade aluminum systems. It forms a true non-metal-to-metal break, drastically reducing heat transfer and condensation.
→ Commonly used in curtain walls and storefronts, now integrated into our folding doors.
Why AZON?
Exceptional impact and shear strength
Superior heat distortion resistance
Complies with HVHZ standards under IBC & Florida Building Code
Helps achieve lower U-Factors and SHGC for energy efficiency
Performance
Description
Material
Aluminum
Panel
Min. Panel Width: 12” (304.8 mm)
Max. Panel Width: 50” (1270 mm)
Number of Panels: Unlimited
Max Unit Height
without structural horizontal mullion
[Max. Unit Height with structural horizontal mullion]
11'6" (3500 mm)
[14'9" (4500 mm)]
Intersection of two folding doors
5 3/64" (128 mm)
Glass Thickness Options
0.6299” (16 mm) / 0.8661” (22 mm)
0.9448” (24 mm) / 1.1024” (28 mm)
1.2598” (32 mm) / 1.2992” (33 mm)
Folding Options
Unlimited (Go to the Fold Options & Special Features Page)
Track Options
Standard Combo Track / Automotive Track /
Freeway Track / HD Track (Go to Tracks for details)
Finish Options
Fropon™ PVdf Resin Coatings
(Go to Finishes for details)
Performance
Center of glass U-Value ≤0.21
Unit U-Value ≤0.28
(NFRC Tested and Labeled)
Wind Design Pressure
Non Impact : ≥ +70 / -105 psf
Impact : ≥ +70 / -70psf
FL-HVHZ / Tested to TAS201/202/203
Water Penetration Resistance
≥ No leakage after 4 cycles of
5 minutes at 504 pa (10.5 psf)
Air Infiltration 0.065 (cfm/ft2)
Air Exfiltration 0.090 (cfm/ft2)
Rounded Reported Value 0.1
Exceeds the requirement x3
Sound Transmission
STC up to 42
Durability
500,000 cycles
Test Passed
